heat exchanger tubes
"
Пробки теплообменного аппарата стали углерода, пробки безшовной стали боилера пара DIN17175
Seamless Steam Boiler Steel Tubes DIN17175 Pressure Vessels and Boilers Seamless steel tubes for pressure purposes-Technical delivery conditions Non-alloy steel tubes with specified elevated temperature properties Applications: for pipelines of boilers industry, vessel equipment Size range: O.D.:6-323mm W.T.:1-30mm L: according to customer requirement Chemical composition Chemical composition Steel grade C Si Mn P S Cr Mo Steel name max max St35.8 0.17 0.10-0.35 0.40-0.80 0
Пробки теплообменного аппарата стали углерода ASTM A210 безшовные средств для перегревателей
ASTM A210 Seamless medium carbon steel boiler and superheater tubes Applications: for Boilers,Superheaters,Steam linepipes of boilers Size range: O.D.:12.7-127mm W.T.:1-15mm L: according to customer requirement Steel Grade and Chemical Compositions: Grade C Mn P S Si A-1 ≤0.27 ≤0.93 ≤0.035 ≤0.035 ≥0.10 C ≤0.35 0.29-1.06 ≤0.035 ≤0.035 ≥0.10 Mechanical properties: Grade Yield Point Mpa(ksi) Tensile Strength Mpa(ksi) Elongation A-1 ≥255(37) ≥415(60) ≥30% C ≥275(40) ≥485(70) ≥30%
АСТМ А179 25,4 длина низкоуглеродистых стали 3-22м трубок теплообменного аппарата Мм безшовных
Round steel tubes heat exchanger tubes ASTM A179 ASME SA179 Applications: for Boilers,Superheaters, Heat-Exchangers, High-pressure Boilers, Steam Boilers Cold Condensers and High-Pressure Services, High-Temperature Services for Boiler Constructions Round steel tubes heat exchanger tubes ASTM A179 ASME SA179 Material: Low Carbon Steel Production: Seamless Cold Drawn Size range: O.D.:3.2-76.2mm W.T.:1-15mm L: according to customer requirement. Steel Grade and Chemical
Обожженные SA178a трубки теплообменного аппарата ASTM A178 ERW
ASTM A178 ERW Carbon Steel Boiler and Suoer Heater Tubes Product Description: ASTM A178 is a specification which covers standards for electric resistance welded tubes, which are abbreviated as ERW SA178 Boiler Tube. These ASTM specified SA178a Boiler Tubes are produced with a minimum wall thickness made from carbon steel alloys as well as carbon- manganese steel. This ASTM SA178 Grade A Electric-Resistance Welded Carbon Steel Boiler Tubes are designed to be used in boiler
Высокий коэффициент передачи тепла прессовал трубки теплообменного аппарата Od10mm
High Heat Transfer Coefficient Extruded Finned Tube And Fin Radiator Heat Exchanger Tubes The finned tube adopts the form of base tube covering aluminum tube, (the base tube can be carbon steel, stainless steel, copper) through machine extrusion to form the fin, the base of the fin is close to the outer wall of the tube, with high heat transfer coefficient and excellent heat transfer performance. Details: Maximum Working Temperature 545 Fin Materials Aluminium Base Tube
Трубки SA213 T12 T11 T5 T22 теплообменного аппарата сплава боилера (2")
SA213 T12 T11 T5 T22 (2") 50,8 MM. Ø O.D. X (0,165") 4,19 MM Boiler Tubes Alloy Heat Exchanger Tubes Quick detail : Origin China Brand name Torich Certificate ISO9001 TS16949 Material SA213 T12 T11 T5 T22 Product name SA213 T12 T11 T5 T22 (2") 50,8 MM. Ø O.D. X (0,165") 4,19 MM Boiler Tubes Alloy Heat Exchanger Tubes Capacity Bending Basic introduction Production method:Seamless Cold drawning Size range: Size: 1/2" - 12" OD, Guage: 25 SWG - 10 SWG OD: 6.35 to 114.3
Трубки теплообменного аппарата ASTM A179 продольные Finned обожгли
TORICH ASTM A179 Longitudinal Finned Heat Exchanger and Superheater Tube Based Tube: ASTM A179 A192 A213 T5 T9 T11 Fin Type: Longitudinal Fins Other Fin Types: According to the fin shape and structure Square finned tube, Sprial finned tube, Longitudinal finned tube, Helical serrated finned tube, Inner finned tube According to the fin material Single metal finned tube, Bimetal composite finned tube According to the processing technology Extruded fin tube, welded fin tube, Roll
Трубка Astm A519 теплообмена опреснения морской воды испарителя
ASTM A516 Gr.70 Tubular Slide Sheet For Evaporator And Seawater Desalination U-shaped expansion joint is commonly used in fixed tubesheet heat exchanger. It has the advantages of compact and simple structure, good compensation and low price. Tubesheet is a kind of fitting that drills a hole slightly larger than the outer diameter of the pipe on the circular steel plate, penetrates the pipe, welds and fixes it. In the calculation of fixed tubesheet, the axial stress of shell,
Трубы теплообменника SA179 ST35.8
SA179 ST35.8 Mild Seamless Steel Round Pipe Thick Wall Pipe Boiler Chemcial Fertilizer Material: Low Carbon Steel Production: Seamless Cold Drawn Size range: O.D.:3.2-76.2mm W.T.:1-15mm L: according to customer requirement. Steel Grade and Chemical Compositions: C 0.06-0.18 Mn 0.27-0.63 P ≤0.035 S ≤0.035 Mechanical Properties Tensile Streghth: min ksi[Mpa] 47[325] Yield Point: min ksi[Mpa] 26[180] Elongation: ≥35% Hardness: ≤72HRB Heat Treatment: Tubes are heat treated after
